| Equipment Parameters |
|---|
| Build Material | Titanium Alloys, Aluminum Alloys, Superalloys, Cobalt-Chromium Alloys, Stainless Steel, Die Steel, Copper Alloys, etc. |
| Build Size ① | 1500×1500×1500mm ( X×Y×Z ) | Recoating Mechanism | Uni/Bidirectional Variable-Speed Recoating |
| Laser System | 500W×16 /×24 | Gas Support | Ar/N₂ |
| Scan System | High-Precision Scanning Galvanometer | Working Oxygen Content | ≤100ppm |
| Focusing System | F-theta Lens | Build Efficiency ② | 320cm³/h; 870cm³/h |
| Beam Quality | M² ≤ 1.1 | Host Dimensions | 10000×6000×8500mm ( L×W×H ) |
| Beam Diameter | 60–120μm | Installation Dimensions | 12000×8000×12000mm ( L×W×H ) |
| Maximum Scanning Speed | 14m/s | Power Supply | AC380V |
| Layer Thickness | 20–100μm | Power Consumption | ≤80kW |
| Platform Preheating Temperature | RT+20℃–200℃ | Equipment Weight | Approx. 40000kg |
1: Excluding the thickness of the build platform.
2: The buiding efficiency can vary due to diferences in equipment corfiguration, process parameters, and the operating status of the laser.
* The above data are cbtained under HG-ATOMl operating condtions. The final equipment parameters are subject to the actually sold products.
