| Equipment Parameters |
|---|
| Build Material | Titanium Alloys, Nickel-Titanium Alloys, Aluminum Alloys, Superalloys, Cobalt-Chromium Alloys, Stainless Steel, Die Steel, Copper Alloys, High-Entropy Alloys, Refractory Metals, etc. |
| Build Size ① | φ 170×120mm ( D×H ) | Recoating Mechanism | Unidirectional Variable-Speed Recoating |
| Laser System | 500W×1 | Gas Support | Ar/N₂ |
| Scan System | High-Precision Scanning Galvanometer | Working Oxygen Content | ≤100ppm |
| Focusing System | F-theta Lens | Build Efficiency ② | 25cm³/h |
| Beam Quality | M² ≤ 1.1 | Host Dimensions | 1400×800×1800mm ( L×W×H ) |
| Beam Diameter | 40-80μm | Installation Dimensions | 3200×2400×2380mm ( L×W×H ) |
| Maximum Scanning Speed | 7m/s | Power Supply | AC220V |
| Layer Thickness | 20~100μm | Power Consumption | 7kW |
| Platform Preheating Temperature | RT+20℃-200℃ | Equipment Weight | Approx. 800kg |
1: Excluding the thickness of the build platform.
2': The building efficiency can vary due to diflerences in equipment conliguration., proces parameters, and the operating status of the laser.
The above data are obtained under HG ATOM operating conditions. The linal equipment parameters are subject to the actually sold products.
